The RSA SecurID Token for Windows and RSA SecurID Token for Mac OSX are convenient form factors that reside on a PC or Mac and enable automatic integration with leading remote access clients. RSA SecurID is a two-factor authentication mechanism based on a one-time passcode (OTP) that is generated by using a token code provided by a software or hardware authenticator. Hunter tools dsp 600 manual. Both BIG-IP Edge Client for Windows and OS X systems support the RSA SecurID feature.

I have a requirement where I need to enter secure Id from RSA token during login authentication and then start running automation test.

Rsa Securid Token Import

Currently Shipping Version RSA SecurID Software Token 4.2.1 for macOS Supported Platforms OS X Sierra (10.12), OS X High Sierra (10.13), OS X Mojave (10.14), OS X Catalina (10.15) Disk Requirements 53 MB Required Components RSA SecurID token seed records (128-bit, AES), sold separately RSA Authenti. ‎Download apps by RSA Security, including RSA Identity G&L, RSA SecurID Software Token, RSA SecurID Authenticate, and many more.

Download RSA SecurID Authenticate and enjoy it on your iPhone, iPad, and iPod touch. ‎The RSA SecurID® Authenticate app works with RSA SecurID Access to provide strong authentication and convenient single sign-on to corporate applications. RSA updates the RSA SecurID Authenticate app on a regular basis. RSA recommends that you always update to the latest version of the app. However, if you are unable to, the following table lists the supported minimum requirements for the Authenticate device.

Is it possible to access the RSA token value programmatically through any api or any other way , so that test flow can be automated completely?

Rsa Token For Mac

3 Answers

We automated our login to a vpn that uses rsa secure id and Cisco AnyConnect, by doing the following:

1) Open rsa secure id programatically the way you want

2) Run the following .ps1

All you need to do now is to set your vpn, and user on the script above.

You need to specify what kind of token you use.

There are number of choices here I heard of:

• hardware token
• software token application (Mac OS, Windows, iOS, Android, Windows Mobile, and few others)
• web browser token

Please check this link for more details:http://www.emc.com/security/rsa-securid/rsa-securid-software-authenticators.htm#!offerings_for_web_browsers

With hardware token you will need to use some kind of camera and read pixels of the image taken (I will not be able to help you there)

Software token is simpler.

I have recently created small command line tool that is able to execute, enter PIN, and read Passcode generated in the token application.I cannot send you the tool (property of my company), but I can give you some tips what you need to do to create your own application that will do the same stuff.

But first you need to tell me whether you use software token or not.

OK.Since you have software token I'll describe what my app do to automatically connect to VPN.

1) you need to have your software token configured prior doing this.
On top of that VPN client will need to be also configured, and connection must be listed on available connection list.
When it is configured you can do your auto VPN Connection.
We have software token similar to this one:
https://ssl.seagate.com/ssl/docs/soft_token_install_instructions.html
Our VPN Client looks looks something like this one:
http://wireless-setup.wsu.edu/msIPSEC.html

2) Once all tools are configured you can start your VPN connection.

You need to be prepared to do deep investigation.
Guys from RSA worked really hard to make it impossible this what we are doing here.
They don't use ordinary controls. They have created their own controls I do not have spec for.

Rsa Securid Token Software Download

I have done it using C++ and WIN32 API functions. This is my recipe. /kindle-cloud-reader-for-mac-5754/.

a) read parameters passed to the program

b) validate the parametersI have number of params like PIN, connection number to establish, Command to run when connection is established etc. They can be hardcoded of course but to be flexible I can pass them from command line.

c) check for token application [EnumWindows]
Token app can have 2 top level windows [The one you enter PIN, and the one with passcode]
If I detect both windows opened I close the app and restart it.
You can try sending Message WM_CLOSE to close the app. I simulate users action to press 'X' close button

To start it I use CreateProcess function.
When you restart the app or you had only one window opened, you can now enter PIN.

d) Enter PIN

I simulate users left click on pin window WM_LBUTTONDOWN, WM_LBUTTONUP.
I enter the pin using WM_CHAR.
Once entered, click OK button using WM_LBUTTONDOWN, WM_LBUTTONUP.
Once completed you should have Passcode window displayed.

e) Read passcode
To get the passcode I use Copy button from the token. This button Copy data to clipboard.
We simulate pressing this button: WM_LBUTTONDOWN, WM_LBUTTONUP
And read data from clipboard:

Now you have Passcode ready to be used in the CISCO VPN Client.
Please let me know if it make any sense to you.
If it does, and you your app works up to this point please let me know and I'll pass instruction to deal with VPN client.

Rsa Securid Software Token Download

If you need more detailed instruction for the steps above please let me know.

One idea is to record a bunch of clock/token pairs and run the clock back for your program and replay the recording. Actually, if you have the option of cooking the clock, you really only need one pair.

(I did not say it was a GOOD idea.)

Good luck,/Bob Bryan

Not the answer you're looking for? Browse other questions tagged securityautomationrsa or ask your own question.

If you experience any problems during the process please contact the Partners Service Desk.

Instructions:

Mac's Enrolled in PEAS

1. Launch Self Service from the Applications folder ( Go menu > Applications)
2. Click on Applications in Categories and the click on the icon labeled RSA SecuID Token

1. Go to step 6 in the manual process section.

Manual Process:

1. Download the Mac SecurID software

2. Once downloaded open the file.

3. Install the application by selecting CONTINUE and following instructions.

Rsa Securid Download Mac Download

4. Select AGREE to accept licensing agreement.

5. After selecting CLOSE installation will complete.

6. Open the email you received with the token and activation information and copy the URL.

7. Open the RSA SecurID application from your LAUNCHPAD and select Import from Web option.

8. In the Enter URL space please copy and paste the URL link you received in your email. In the Enter Activation Code space please copy and paste the activation code you received and click OK.

9. You should get a Successful Import message. You may also change the name of the token to something more familiar if you wish and click OK.

10. Your token is now ready for use.
